splash Namespace Reference

Classes
class	AttributeInfo
class	CollectionType
class	ColTypeBool
class	ColTypeDim
class	ColTypeDimArray
class	ColTypeString
class	ColTypeUnknown
class	DataCollector
class	DataContainer
class	DCException
class	Dimensions
class	Domain
class	DomainCollector
class	DomainData
struct	DomainH5Ref
struct	H5IdWrapper
class	IDomainCollector
class	IParallelDataCollector
class	IParallelDomainCollector
class	ParallelDataCollector
class	ParallelDomainCollector
class	Selection
class	SerialDataCollector

Typedefs
typedef H5IdWrapper< H5Aclose, policies::NoCopy >	H5AttributeId
typedef H5IdWrapper< H5Aclose, policies::RefCounted >	H5AttributeIdRefCt
typedef H5IdWrapper< H5Sclose, policies::NoCopy >	H5DataspaceId
typedef H5IdWrapper< H5Sclose, policies::RefCounted >	H5DataspaceIdRefCt
typedef H5IdWrapper< H5Tclose, policies::NoCopy >	H5TypeId
typedef H5IdWrapper< H5Tclose, policies::RefCounted >	H5TypeIdRefCt
typedef H5IdWrapper< H5Oclose, policies::NoCopy >	H5ObjectId
typedef H5IdWrapper< H5Oclose, policies::RefCounted >	H5ObjectIdRefCt

Enumerations
enum	DCDataType {   DCDT_UNKNOWN, DCDT_FLOAT32, DCDT_FLOAT64, DCDT_INT32,   DCDT_INT64, DCDT_UINT32, DCDT_UINT64 }

Functions
void	swap (AttributeInfo &lhs, AttributeInfo &rhs)
CollectionType *	generateCollectionType (hid_t datatype_id)
	TYPE_ARRAY (Float2, H5T_NATIVE_FLOAT, float, 2)
	TYPE_ARRAY (Float3, H5T_NATIVE_FLOAT, float, 3)
	TYPE_ARRAY (Float4, H5T_NATIVE_FLOAT, float, 4)
	TYPE_ARRAY (Double2, H5T_NATIVE_DOUBLE, double, 2)
	TYPE_ARRAY (Double3, H5T_NATIVE_DOUBLE, double, 3)
	TYPE_ARRAY (Double4, H5T_NATIVE_DOUBLE, double, 4)
	TYPE_ARRAY (Int2, H5T_NATIVE_INT, int, 2)
	TYPE_ARRAY (Int3, H5T_NATIVE_INT, int, 3)
	TYPE_ARRAY (Int4, H5T_NATIVE_INT, int, 4)
	TYPE_ATOMIC (Float, H5T_NATIVE_FLOAT, float)
	TYPE_ATOMIC (Double, H5T_NATIVE_DOUBLE, double)
	TYPE_ATOMIC (Int, H5T_NATIVE_INT, int)
	TYPE_ATOMIC (Char, H5T_NATIVE_CHAR, char)
	TYPE_ATOMIC (UInt8, H5T_INTEL_U8, uint8_t)
	TYPE_ATOMIC (UInt16, H5T_INTEL_U16, uint16_t)
	TYPE_ATOMIC (UInt32, H5T_INTEL_U32, uint32_t)
	TYPE_ATOMIC (UInt64, H5T_INTEL_U64, uint64_t)
	TYPE_ATOMIC (Int8, H5T_INTEL_I8, int8_t)
	TYPE_ATOMIC (Int16, H5T_INTEL_I16, int16_t)
	TYPE_ATOMIC (Int32, H5T_INTEL_I32, int32_t)
	TYPE_ATOMIC (Int64, H5T_INTEL_I64, int64_t)
	TYPE_COMPOUND (Float2, H5T_NATIVE_FLOAT, float, 2)
	TYPE_COMPOUND (Float3, H5T_NATIVE_FLOAT, float, 3)
	TYPE_COMPOUND (Float4, H5T_NATIVE_FLOAT, float, 4)
	TYPE_COMPOUND (Double2, H5T_NATIVE_DOUBLE, double, 2)
	TYPE_COMPOUND (Double3, H5T_NATIVE_DOUBLE, double, 3)
	TYPE_COMPOUND (Double4, H5T_NATIVE_DOUBLE, double, 4)
	TYPE_COMPOUND (Int2, H5T_NATIVE_INT, int, 2)
	TYPE_COMPOUND (Int3, H5T_NATIVE_INT, int, 3)
	TYPE_COMPOUND (Int4, H5T_NATIVE_INT, int, 4)
template<H5_DLL herr_t(*)(hid_t) T_CloseMethod, template< class > class T_DestructionPolicy>
bool	operator== (const H5IdWrapper< T_CloseMethod, T_DestructionPolicy > &lhs, const H5IdWrapper< T_CloseMethod, T_DestructionPolicy > &rhs)
template<H5_DLL herr_t(*)(hid_t) T_CloseMethod, template< class > class T_DestructionPolicy>
bool	operator!= (const H5IdWrapper< T_CloseMethod, T_DestructionPolicy > &lhs, const H5IdWrapper< T_CloseMethod, T_DestructionPolicy > &rhs)
EXTERN void	parseEnvVars (void)
EXTERN void	setLogMpiRank (int rank)
EXTERN void	log_msg (int level, const char *fmt,...)

Variables
static const char *	COMPOUND_ELEMENTS [] = {"x", "y", "z", "u", "v", "w"}
static int	verbosity_level = 0
static int	my_rank = 0

Detailed Description

Copyright 2013-2016 Felix Schmitt, Axel Huebl, Alexander Grund

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013-2014 Felix Schmitt

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013-2015 Felix Schmitt, Axel Huebl

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013-2016 Felix Schmitt, Alexander Grund

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013 Felix Schmitt 2015 Carlchristian Eckert

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013-2015 Felix Schmitt, Axel Huebl, Carlchristian Eckert

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013, 2015 Felix Schmitt, René Widera, Axel Huebl, Carlchristian Eckert

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013-2016 Felix Schmitt, Axel Huebl, Carlchristian Eckert, Alexander Grund

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2015 Carlchristian Eckert

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2015-2016 Carlchristian Eckert, Alexander Grund

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013, 2015 Felix Schmitt, Axel Huebl

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2013 Felix Schmitt

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2016 Alexander Grund

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Copyright 2014-2015 Felix Schmitt, Axel Huebl

This file is part of libSplash.

libSplash is free software: you can redistribute it and/or modify it under the terms of of either the GNU General Public License or the GNU Lesser General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

libSplash is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License and the GNU Lesser General Public License for more details.

You should have received a copy of the GNU General Public License and the GNU Lesser General Public License along with libSplash. If not, see http://www.gnu.org/licenses/.

Typedef Documentation

H5AttributeId

typedef H5IdWrapper<H5Aclose, policies::NoCopy> splash::H5AttributeId

Wrapper for HDF5 attribute identifiers

Definition at line 153 of file H5IdWrapper.hpp.

H5DataspaceId

typedef H5IdWrapper<H5Sclose, policies::NoCopy> splash::H5DataspaceId

Wrapper for HDF5 space identifiers

Definition at line 156 of file H5IdWrapper.hpp.

H5ObjectId

typedef H5IdWrapper<H5Oclose, policies::NoCopy> splash::H5ObjectId

Wrapper for HDF5 type identifiers

Definition at line 162 of file H5IdWrapper.hpp.

H5TypeId

typedef H5IdWrapper<H5Tclose, policies::NoCopy> splash::H5TypeId

Wrapper for HDF5 type identifiers

Definition at line 159 of file H5IdWrapper.hpp.

Enumeration Type Documentation

DCDataType

enum splash::DCDataType

Possible data types.

Definition at line 41 of file DCDataSet.hpp.

Function Documentation

generateCollectionType()

CollectionType * splash::generateCollectionType

(

hid_t

datatype_id

)

Creates a new instance of a CollectionType based on the given datatype_id

Parameters

datatype_id

the H5 datatype_id that should be converted into a CollectionType

Returns

A pointer to a heap-allocated CollectionType. The allocated object must be freed by the caller at the end of its lifetime. If no matching CollectionType was found, returns a ColTypeUnknown instance.

Definition at line 65 of file generateCollectionType.cpp.

Here is the caller graph for this function:

log_msg()

void splash::log_msg	(	int	level,
		const char *	fmt,
			...
	)

writes a log message for a given log level

Parameters

level	required log level
fmt	format string (like printf)
...	arguments to fmt

Definition at line 56 of file logging.cpp.

Here is the caller graph for this function:

parseEnvVars()

void splash::parseEnvVars

(

void

)

parses environment variables and sets internal configuration

Definition at line 41 of file logging.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

setLogMpiRank()

void splash::setLogMpiRank

(

int

rank

)

sets the MPI rank to be used for log messages

Parameters

rank

MPI rank

Definition at line 51 of file logging.cpp.

Here is the caller graph for this function:

Variable Documentation

my_rank

int splash::my_rank = 0

static

current MPI rank for log messages

Definition at line 39 of file logging.cpp.

verbosity_level

int splash::verbosity_level = 0

static

current verbosity level for log messages

Definition at line 34 of file logging.cpp.
